LEDs

  • LED stands for Light Emitting Diode.
  • An LED is semiconductor device that emits light due to Electroluminescence effect.
  • LEDs are used in almost each electronical device as indicators.
PLCC 5050
PLCC 5050
PLCC 5050 Package(1.6T) LED

■ 5.4 mm X 5.0 mm SMD LED, 1.6 mm thickness
■ High Luminous Intensity
■ Single Color and RGB Color
■ Wide viewing angles : 120 degree
■ Suitable for all SMT assembly methods
■ RoHS compliant
Type Part No. Lighting Color Dominant Wavelegth
 (nm)		 Luminous Intensity
IV(Mcd) @IF=5/20mA		 Forward Voltage(v) Viewing Angle2
1/2
Typical Typical Min Max Typ
5050 3CHIP L5050QRC Ultra Red 624 1400 1.8 2.4 120
L5050QYOC Ultra Orange 604 1400 1.8 2.4 120
L5050QYC Ultra Yellow 588 1400 1.8 2.4 120
L5050QGC Ultra Yellow Green 572 500 1.8 2.4 120
L5050PGC Ultra Dark Green 560 500 1.8 2.4 120
L5050QBGC Ultra Green 518 3000 2.6 3.4 120
L5050QBC Ultra Blue 465 1200 2.6 3.4 120
L5050QWD White X=0.29, Y=0.28 8000 2.6 3.4 120
L5050QWYD Warm White X=0.42, Y=0.43 8000 2.6 3.4 120
5050 FULL-COLOR L5050QRQBGQBC Ultra Red 624 600 1.8 2.4 120
L5050QRQBGQBC Ultra Green 525 1200 2.8 3.6 120
L5050QRQBGQBC Ultra Blue 468 500 2.8 3.6 120
